© Axiom Electronics Electronics Production | October 24, 2022

Axiom adds 3D AOI capability

Oregon-based EMS provider, Axiom Electronics, has added inline 3D AOI capability to its SMT area with the addition of three CyberOptics SQ3000 AOI systems.

Axiom Electronics assembles and tests complex circuit boards and complete systems for prototype, pilot run and production builds.

The SQ3000’s four multi-view 3D sensors and parallel projector deliver metrology-grade accuracy at production speed. Its key advantage is the ability to analyse multiple images simultaneously eliminating reflections caused by shiny components and reflective solder joints. The system also supports larger form factor boards up to 710 x 610 mm.

“Manual visual inspection is subjective and 2D AOI inspection can generate enough false positives that it slows down the inspection process. This system’s 3D measuring capabilities provide a more accurate and repeatable automated inspection process which we believe will improve factory cycle time and provide more precise feedback about product quality,” says Rob Rowland, Director of Engineering Operations, in a press release.

The team is also using the machines’ real-time statistical feedback to analyse quality trends and drive corrective actions.

“Inspection data helps us identify areas where a need to fine-tune paste deposition, component placement or reflow soldering is necessary. It can also be an early indicator of machine or tooling wear-driven variation. This helps reduce defect opportunities and the cost of quality,” Rowland explains.
