RoodMicrotec invests in new AOI system

Starting in the first quarter of 2019 the STI iFocus 505 will add a wide range of new possibilities to the company’s portfolio of services. “The purpose of this service is to detect failures and damages on incoming wafers and assurance of quality on outgoing wafers. It will enable us to identify possible defects resulting from earlier processing steps, such as wafer manufacturing and transport, and deliver products of the best possible quality to our customers. We will furthermore be able to stand out as a strong, reliable and quality-delivering partner for all customers in the semiconductor industry by implementing this kind of machine into the existing production landscape,” says Martin Sallenhag, CEO of RoodMicrotec. The AOI system is able to automatically handle 6, 8 and 12-inch wafers from cassette to cassette. It also offers the possibility to handle and inspect whole or partial wafers, mounted on film frame. The two main parts of the system are the handling-unit and the vision-unit. The handling-unit consists of a robot that handles the wafers and guides them from the cassette to the vision-unit. The vision-unit includes the movable chuck on high precision linear motors, and the powerful vision system right on top of it. The complete system is mounted on a block of granite weighing half a ton and lying on four air dampers to provide the necessary stability and to compensate vibrations. The throughput of the system depends on the magnification applied. Mainly 5X is used but the machine is also capable of 2.5X, 3.5X, 7.5X and 10X. The magnification determines the size of defects that can be detected. At 10X for example, defects of the size of 1.6µm x 1.6µm can be found.
