© Arrow Components | October 01, 2013

Arrow introduces: the AT-501 SoM

Arrow Electronics has introduced a system-on-module (SoM) package that will provide engineers with access to the full functionality of the ARM CortexTM-A5 microcontroller core.
The AT-501 SoM was developed by Arrow in conjunction with Shiratech, Israel. It utilises an Atmel SAMA5D3 ARM CortexTM-A5 based MCU and combines high performance and low-power consumption with a range of peripheral support. This makes it suitable as a platform for developing mobile and battery-powered embedded systems that demand minimal energy usage in order to achieve extended periods of operation.

In addition to the processing unit, it comes complete with 256 MB DDR2 and flash memory, a built-in 1G Ethernet, an internal system clock and a 200-pin SO-DIMM connector via which all the supported interfaces are available. The SoM measures 68 x 47mm and uses a single 3.3V power input.

Boot and operating system software is supplied, including the Debian Linux distribution and in versions for internal flash and SD card, together with software support for available interfaces. Sample applications for web server, CLI and SNMP agent and a software package for secured software upgrade and version control are also available. Integration is further simplified by a configuration tool that defines pin-outs. A Linux OS and tools is also available from Timesys corporation (USA).

The SAMA5D3 MCU can deliver 850 DMIPS with power consumption of less than 200mW when fully loaded and supports an operating bandwidth of up to 1328 MB/s with a 166 MHz bus speed.
